SPAN500W Enhanced
- 在线询价
Features:
The distance between the rungs is 500mm, and another side is embedded with a 250mm straight ladder,It can also choose a special 45 ° or 70 ° inclined ladder
Fluted ladder rungs forincreased slip resistance when climbing
TIG welded joints give strength and durability Anti-slip plywood platform available in standard and trapdoor formats
All of the braces and stabilisers adopt cold expansion, cold pressing or cold processing technology, which is solid, durable and pressure resistant
Adjustable Leg gives up to 400mm of adjustment for quick and easy levelling
WhatsApp：(+086)18620951155
- 产品描述
- 产品参数
- 文档下载
The SPAN500W-D enhanced series products are designed and manufactured in strict accordance with the EU EN1004 Class 3 (Class 3 load standard), and have obtained the original German TUV safety certification.
SPAN500W-D adopts a strong and firm 50.0mm diameter, 2.0mm wall thick aluminum alloy pattern pipe, the main frame adopts the traditional argon arc welding welding technology, with cold expansion and cold pressure manufacturing process of the pull rod design, is an economic aluminum alloy working platform, to meet the needs of ordinary high altitude work. This series of products follow the 3T construction method (through the movable board), with the patented structure of the "rhino nose" fast lock pull rod, can safely and quickly lock the frame. No tools are required for assembly and disassembly.
INSTANT SPAN500W Enhanced series products are designed and manufactured in strict accordance with the EU EN1004 Class 3 (Class 3 load standard), and have obtained professional TUV safety load certification.
The reinforced series of products use a strong and firm 50mm diameter, 2.0mm wall thick aluminum alloy pipe, the main frame of the robot argon arc welding welding technology, with cold expansion and cold pressure manufacturing process of the pull rod design, is a strong, high strength, durable product. It is designed for the special situation of China's construction market, especially suitable for construction sites and other harsh working environment.
This series of products follow the 3T construction method, the self-locking pull hook can be safe and fast to lock the frame. No tools are required for assembly and disassembly.
- The frame ladder spacing is 500mm, and a vertical ladder with a spacing of 250mm is embedded on the other side, which is convenient and safe
- Optional dedicated 45 or 70, inclined ladder
- High strength aluminum alloy tube with diameter of 50mm for excellent slip resistance
- Aluminum alloy main wall thickness of 2.0mm, anti-fall, pressure resistance and touch resistance
- All braces and stabilisers shall adopt cold expansion and cold pressing or cold processing technology, which is firm, durable and pressure resistant
- The frame adopts high strength argon arc welding welding process, TUV safety certification
- With 0.4m adjustable legs up to any height
- Safety load bearing 900Kg, single-layer working platform safety load bearing 275Kg
- Designed and manufactured according to the EU EN1004 standards
- Comply with EU Class 3 load standards for EN1004, BS1139 and WAHR
- Product warranty for 2 years
