SPAN300W/400W Welded
Features
The distance between all of the rungs is 400mm , It can also choose a special 45 ° or 70 ° inclined ladder
Fluted ladder rungs for increased slip resistance when climbing
TIG welded joints give strength and durability
Anti-slip plywood platform available in standard and trapdoor formats
All of the braces and stabilisers adopt cold expansion , cold pressing or cold processing
technology, which is solid , durable and pressure resistant
Adjustable Leg gives up to 400mm of adjustment for quick and easy levelling
- Product Description
- Specifications
- Downloads
SPAN300W/400W series products are designed and manufactured in strict accordance with EU EN1004 Class 3 (Class 3 load standard), and have obtained professional TUV safe load certification.
This series of products are designed for the special situation of the Chinese construction industry market (workers generally do not cherish tools and instruments, low level of using and other characteristics). It uses a strong and solid 50mm diameter, 2.0mm wall thickness aluminum alloy pipe. The main frame uses robot argon arc welding technology, and the brace design with cold expansion and cold pressing manufacturing.The process is a solid, high strength, pressure resistant and durable product. Especially suitable for construction site environment.
This series of products follow the 3T construction method (through the movable board), with a patented "rhinoceros nose" quick locking rod, which can safely and quickly lock the frame. No tools are required for assembly and disassembly.
The enhanced SPAN300W/400W series is the most common product on the market, and its main features are as follows:
▷ The frame ladder spacing is 400mm (that is 5-level ladder spacing every 2 meters high), which meets the safety standards of all countries around the world, and meets the two sides of the tower can be used as a direct ladder, which is extremely convenient and flexible
▷ So the frame span is added by 0.4 meters, with the adjustable leg up to any height, with a dedicated 45 or 70 ramp ladder optional
▷ High strength aluminum alloy tube with a diameter of 50mm for excellent slip resistance
▷ The main wall thickness of aluminum alloy is 2.0mm, falling, pressure and touch
▷ Safety load bearing 900Kg, single-layer working platform safety load bearing 275Kg, designed and manufactured in accordance with the EU EN1004 standard
▷ All of the braces and stabilizers adopt cold expansion , cold pressing or cold processing technology, which is solid , durable , pressure resistant and easy to repair, maintenance and replacement of accessories
▷ The frame adopts high strength argon arc welding welding process, TUV safety certification
▷ Comply with EU Class 3 load standards for EN1004, BS1139 and WAHR
▷ Warranty 2 years
Product details
